HS5 Walk-In Chemical Store
Dimension: H2658 x W3000 x D2440
Backed by our 20 year structural guarantee*
The base is manufactured from 3mm mild steel sheet with pressed ribs. All the corner posts, main rails and cross members are from rolled hollow section. The roof is pressed as required with suitable bracing and fully welded around the perimeter, while the back, side and door panels are pressed from 2mm mild steel sheet and corrugated where required.
The bulkhead door is 1,250mm wide and fitted with a single cam door gear which is secured with a padlock (not supplied).
Inside the unit there are shelving units either side of the door, the fully seam welded sump is fitted with a removable galvanised grid mesh deck and high and low level louvre vents complete with flame arrestor mesh are fitted as standard. The unit is shot blasted before being painted.
The sump fully complies with all the UK regulations relating to sump capacities.
- Storage Capaciry: 72 x 25ltr containers
- Sump capacity: 1098ltr
- Unit weight: 1350kg
- Colour: Green RAL 6029
Lead time: 6-8 weeks (made to order)
